WT10A gauss meter, magnets, magnetic separator WT10A gauss meter NS, MT unit display(battery not included)
WT10A is handheld digital gauss meter,used for measure the surface field of the permanent magnet material,DC motor,loudspeaker,magnetic separator,the working field of RCYB and leakage field,Demagnetizationresidual magnetic field of after machining parts.
Instruction
WT10A is the first hand-held type Gauss meter of WT series Gauss meters. This instrument is the magnetic field measuring instrument specially designed for field measurement. Its design concept of lightness, practicality and portability has been determined at the beginning of instrument design and its unique design of micro power consumption allows its battery life to be greatly improved.
I Main characteristics
With small volume, light weight and convenient carry, this instrument can meet the measurement requirements of various sites;
. Adopt micro power consumption design With long service life, the battery can be continuously used for more than 50 hours;
Can select transverse probe or axi al probe;
Have judgment function of magnetic field polarity.
II Main technical index
Supply voltage: One 9V laminated cell
Display meter: 3 1/2 digital display
Measurement scope:0 ~200mT,0 ~2000mT
Accuracy: 1%
Resolution: 0.1mT
Temperature error: -0.06% / ° C
Operating environment: Temperature: -10 ° C~40 ° C, humidity: 35~75%
